Airmax Fountain Mooring Kit
Keep Your Fountain Exactly Where You Want It
The Airmax Mooring Kit is a complete shoreline-to-fountain anchoring package - two shore stakes, two stainless carabiners, four cable clamps, and 150 to 500 ft of black vinyl-coated galvanized wire. Everything you need to hold any floating fountain in position against wind and wave action, whether the fountain sits 20 ft from shore in a small residential pond or 250 ft out in the middle of a half-acre HOA lake.
Compatible with every Airmax floating fountain (EcoSeries, PondSeries, SolarSeries, LakeSeries) and works with any other brand of floating fountain with a compatible tie-down point. Vinyl coating keeps the wire from galvanic reaction with pond water and prevents skin injuries during install. Two cable clamps come pre-installed on the mooring lines - just uncoil, run through the fountain tie point, secure with the remaining clamps, and drive the stakes.
Pick your length by measuring from the fountain out to the shore anchor points. The 150 ft kit ships as two 75 ft sections - typical for backyard residential ponds. The 250 ft kit ships as two 125 ft sections for mid-size ponds up to 1/4 acre. The 500 ft kit ships as one 500 ft section for large ponds, HOA lakes, and commercial installs where you may need a single long run.
Anchor your floating fountain. The Airmax Mooring Kit is a complete shoreline-to-fountain kit with stakes, stainless carabiners, cable clamps, and black vinyl-coated galvanized wire in 150, 250, or 500 ft lengths. Everything you need to hold any floating fountain in position against wind and wave action.
Works with every Airmax fountain (EcoSeries, PondSeries, SolarSeries, LakeSeries) and any other brand of floating fountain with a compatible tie-down point.
Pick length by measuring from the fountain out to the shore anchors. 150 ft (two 75 ft sections) for backyard residential ponds; 250 ft (two 125 ft sections) for mid-size ponds up to 1/4 acre; 500 ft (single section) for large ponds and HOA lakes.
Free shipping on every mooring kit. Call (470) 354-1969 for sizing help.
Mooring Kit Size Comparison
| 150 ft Kit | 250 ft Kit | 500 ft Kit | |
|---|---|---|---|
| Airmax Part # | 651052 | 651054 | 651055 |
| Total Mooring Line | 150 ft | 250 ft | 500 ft |
| Line Configuration | Two 75 ft sections | Two 125 ft sections | One 500 ft section |
| Included Stakes | 2 | ||
| Included Carabiners | 2 | ||
| Included Cable Clamps | 4 (2 pre-installed on the mooring lines) | ||
| Wire Material | Black vinyl-coated galvanized steel cable | ||
| Recommended For | Backyard residential ponds; fountain 20-75 ft from shore | Mid-size ponds up to 1/4 acre; fountain 75-125 ft from shore | Large ponds, HOA lakes, commercial installs; fountain up to 500 ft from a single anchor |
Requirements & What to Know Before You Buy
- Fountain Compatibility: works with all Airmax floating fountains (EcoSeries, PondSeries, SolarSeries, LakeSeries) and any other brand of floating fountain with a compatible tie-down point on the float.
- Measure First: measure from the fountain's intended location out to the shore anchor points on both sides. The mooring line runs from stake to fountain to stake (or corner to corner), so total run length = shore-to-fountain + fountain-to-shore.
- 150 ft Kit: two 75 ft sections. Standard for backyard residential ponds where the fountain sits 20-75 ft from either shore.
- 250 ft Kit: two 125 ft sections. For mid-size ponds up to 1/4 acre with the fountain 75-125 ft from shore.
- 500 ft Kit: a single 500 ft section. Best when you need one continuous run - large ponds, HOA lakes, or when the anchor points are not directly across from each other.
- Shore Anchor Points: the included stakes are galvanized steel and drive into soil. On rocky or paved shorelines you may need to substitute a concrete anchor or heavy dock cleat.
- Slack: leave 5 to 10 percent slack in the mooring line so the fountain can rise and fall with rain events and seasonal water-level changes. Too tight and the line pulls the fountain under during heavy rain.
- Winter: mooring line stays in place year-round on ponds that ice over lightly. In deep-freeze climates, disconnect the fountain from the mooring at the carabiners before ice forms so the moving ice sheet does not stress the float.
- Sizing Help: Call (470) 354-1969 with your pond dimensions and we will confirm which kit fits.
What's Included & Optional Add-Ons
- Mooring Line - 150 / 250 / 500 ft of black vinyl-coated galvanized steel cable (2 sections on the 150' and 250' kits; single section on the 500' kit)
- 2 Steel Stakes - galvanized, drive into shoreline soil
- 2 Stainless Carabiners - clip onto fountain tie-down point
- 4 Cable Clamps - 2 pre-installed on the mooring lines; 2 spare for shore-side termination
- Optional Concrete Anchor: for paved or rocky shorelines where the driven stakes are not usable (sold separately)
- Optional Extra Cable Clamps: sold separately if you need to terminate more shore-side connections
Airmax Mooring Kit Specifications
| Manufacturer | Airmax, Inc. (Armada, Michigan) |
| Models | 651052 (150 ft), 651054 (250 ft), 651055 (500 ft) |
| Type | Fountain shoreline anchoring kit |
| Wire Material | Black vinyl-coated galvanized steel cable |
| Included Stakes | 2 galvanized steel stakes (per kit) |
| Included Carabiners | 2 stainless carabiners (per kit) |
| Included Cable Clamps | 4 clamps (2 pre-installed on mooring lines) |
| Line Configuration | 150 ft: two 75 ft sections | 250 ft: two 125 ft sections | 500 ft: single 500 ft section |
| Fountain Compatibility | All Airmax floating fountains and any other brand with a compatible tie-down point |
| Applications | Backyard residential ponds, HOA lakes, resort water features, commercial installations |
| Country of Origin | Made in USA (Armada, MI) |
